Model Name ATS2A7 ATS2A10 ATS7 ATS10
Display 7" TFT LCD
800*480

350cd
10.2" TFT LCD
800*480

350cd
7" TFT LCD
(260,000 Color)
800*480
300cd
10.2" TFT LCD
(260,000 Color)
800*480
350cd
CPU S5PC100 (ARM CORTEX A8, 800MHz) S3C2450(533MHz)
Memory SDRAM 256MB + NAND Flash 256MB Mobile DDR(266MHz) 128MB + NAND Flash 128MB
Serial Port RS232 2 Ports, RS485 1 Port 2 RS-232C, 1 RS-485/232C Option
USB 2 Ports USB 2.0 1Port(High Spped : 480 Mbps), Host : USB 1.1 Port(Full Speed)
Audio 1 Port (Stereo Earphone Jack) Internal Speaker(0.8W),
Audio Out(3.5 Audio Jack)
Ethernet 1 Port (10/100BASE-T) 100Base-T LAN 1 Port
SD Card 1 Port SD Card 1 slot (4 Giga supported)
OS Windows CE 6.0 Windows Embedded CE 6.0
Voltage DC 12V~24V DC12V ~ 24V
Power consumption 8.8W 6W 10W
Max Current 733mA 733mA 500mA 800mA
Size(mm) 210(H)*135(V)*35(D) 284(H)*163(V)*56(D) 222(H)*152(V)*56(D) 284(H)*163(V)*56(D)
Weight 650g 1040g 650g 1040g
Waterproof IP65 -
Operating Temperature 0~70˚C 0 ~ 70˚C
